Smart Injection Well · Lahore

Know what your
water is doing.

Public, read-only visibility for rainwater quality, storage level and discharge—streamed directly from the SmartWell Experimental Setup.

View live dashboard ↘Open live model →
5 ft / 1524 mm13 in ID
PKT --:--:--Firebase · /smartwell/public_live
PUBLIC LIVE MONITORING

Water conditions, at a glance.

iConnecting…Waiting for the first public telemetry record
◎NA

Turbidity

—NTU
ADC ——
◎NA

Water level

—cm
Level ——
◎TDS LIMITED CALIBRATION

Total dissolved solids

NAppm
NA ppt · NA—
◎WAITING

Flow rate

—L/min
Session — L—
DeviceConnecting…
UltrasonicNA
Full-water statusNA
System faultNA
INTERACTIVE DIGITAL TWIN

SmartWell Live System Model

Technical cross-section · 5 ft × 13 in · select any marked component

5 ft / 1524 mm13 in / 330 mm IDCOALFILTER SANDAGGREGATEESP32-S3RELAY I/O01326395265LIVE LEVEL · CMLEVEL UNAVAILABLETurbidityInlet valveMeshUltrasonic · below meshControllerTDSFlushing valveFlow sensor
SESSION HISTORY

Live telemetry trend

CurrentNA MinimumNAMaximumNAAverageNA
Waiting for genuine Firebase samples

Session history · null and unavailable readings remain gaps · up to 120 incoming snapshots retained in this browser tab

SAFE DATA ARCHITECTURE

Public insight.
Private operations.

The public interface reads selected monitoring values only. Full operational status, command traffic and acknowledgements remain separated behind authenticated Firebase paths.

01

/smartwell/public_live

Read-only public monitoring fields. No device credentials and no write controls.

02

/smartwell/private_live

Full operational state reserved for an approved administrator UID.

03

/smartwell/commands

Locked until Security Rules and ESP32 command validation are commissioned.

04

/smartwell/command_status

Device acknowledgements for Pending, Accepted, Executing, Completed, Failed or Expired states.

SECURE OPERATIONS

Administrator control dashboard

Approved Firebase administrators can operate the monitored valves remotely. Every command is validated by Firebase Security Rules and re-checked by the ESP32 safety interlocks before physical actuation.

01
THE PROJECT

A civil engineering system with a digital nervous system.

SmartWell is a final-year project exploring managed rainwater recharge as a practical response to urban flooding and groundwater stress.

The experimental setup uses a transparent 5-mm acrylic tank, graded filter media, a geotextile-wrapped perforated pipe and a three-foot storage chamber.

Its contribution is sensor-led monitoring and motorized control, with water quality checked at entry and storage and discharge conditions observed in real time.

SMART INJECTION WELL

Experimental Setup and
Intelligent Water Monitoring System

PROJECT CREDITS

School of Engineering
University of Management and Technology

ACADEMIC AFFILIATIONUniversity of Management and Technology logoLAHORE · PAKISTAN
Engr Zaigham Ali — SmartWell project credit
Engr Zaigham Ali
Engr Ahmad Qamar — SmartWell project credit
Engr Ahmad Qamar
Project Supervisor Engr Saima Nouman — SmartWell project credit
Project Supervisor · Engr Saima Nouman
